1. 采用整體床身HT250-300高強度樹脂砂鑄造，并經時效處理，床身、立柱、橫滑座、工作臺成C型布局，基礎牢固，框架穩定。
2. X,Y,Z三軸采用重載直線滾動導軌，具有低噪聲，低磨阻的特點,動態響應靈敏，精度穩定性高，主軸箱采用滾柱導軌滑塊安裝，切削剛性大幅提高；
3. X,Y,Z三軸采用墊片式預拉伸結構，軸向剛性大幅提高且精度更穩定
4. 伺服進給系統采用交流伺服電機驅動與絲杠直接傳動，提高傳動精度。
5. 炮筒式短鼻主軸，整體裝調，維修方便，快捷 。
6.工作臺底部采用三滑塊結構，使承載更加均勻且穩定可靠。
9. 選用進口滾珠絲桿（THK、NSK、HIWIN、PMI）及大品牌主軸軸承和絲桿軸承（NSK、SKF、FAG）；
1.The integral bed ht250-300 high-strength resin sand is used for casting, and after aging treatment, the bed, column, sliding seat and worktable form a C-shape layout, with firm foundation and stable frame.
2. the X, y and Z axes adopt the model of linear rolling guide rail, which has the characteristics of low noise and low wear resistance, sensitive dynamic response and high precision stability, and is suitable for high-precision processing in large quantities;
3. x, y and Z axes adopt pre stretching structure to enhance rigidity and offset thermal deformation
4. the servo feed system is driven by AC servo motor and directly driven by lead screw to improve the transmission accuracy.
5. the barrel type spindle assembly is installed and adjusted as a whole, and the maintenance is convenient and fast.
6. temperature controlled spindle. The spindle sleeve is equipped with a circulating groove outside for constant temperature cooling, so as to keep the spindle temperature rise to the lowest during processing and ensure stable processing accuracy. (optional)
7. the spindle is equipped with a position encoder, which not only realizes the precise determination, but also has the function of rigid tapping.
8. a stable and reliable automatic tool exchange system (ATC) is equipped with a mechanical cam type tool magazine and a manipulator. The action is controlled by the mechanical cam. The tool change is rapid and reliable, and the tool change time is 1.8 seconds.
9. imported ball screw (THK, NSK, HIWIN, PMI) and big brand spindle bearings and screw rod bearings (NSK, SKF, FAG) shall be selected.
